Three Phase Single Source Multifunction Meter
4500 INR/Piece
Product Details:
- Product Type Multifunction Meter
- Measuring Voltage Range 240 Volt (v)
- Operating Temperature 27 Celsius (oC)
- Frequency (MHz) 50 Hertz (HZ)
- Color transparent And White
- Click to View more
X
Three Phase Single Source Multifunction Meter Price And Quantity
- 4500 INR/Piece
- 10 Piece
Three Phase Single Source Multifunction Meter Product Specifications
- 50 Hertz (HZ)
- transparent And White
- 27 Celsius (oC)
- Multifunction Meter
- 240 Volt (v)
Three Phase Single Source Multifunction Meter Trade Information
- Cash Advance (CA) Cash in Advance (CID)
- 500 Piece Per Month
- 1 Months
- Yes
- Sample costs shipping and taxes has to be paid by the buyer
- Western Europe Australia Central America Eastern Europe Middle East South America Asia North America Africa
- All India
Product Description
We have been serving our respected clients since 2016 by manufacturing and supplying excellent quality Three Phase Single Source Multifunction Meter. Offered meter matches the accuracy requirements of class 1.0s as per IS13779 and is available in different versions. This source meter with two energy registers is suitable for residential, commercial and LT industrial loads. We have hired a dedicated team of quality analysts who are in charge of checking and inspection of Three Phase Single Source Multifunction Meter on well defined parameters.
Features:
- High accuracy
- Strong construction
- Long lasting functional life
Specification
Phase | Three |
Brand | PES ELECTRICAL |
Usage/Application | Commercial |
Type | Digital |
Product Specifications
- Measure Standard - IS: 13779,
- Dimension (L x W x H) -225 x 175 x 85 (mm)
- Weight (kg)- 2 kg
- Starting current- 20mA
- Accuracy class- Active: class1.0
- Measure parameter-KWH; KW MD, Kvah, Kva
- Other functions- Measure AC Main Power and DG supply Configure to Prepaid and Postpaid
- Meter type- 3 Phase; 4 Wire system
- Rating current/voltage- 10-60 A, 3x240v/ 415v
- Meter impulse- 1000 imp/kWh
- Environment Temperature -Operating temperature range: -100C +600C
- Power consumption- V Circuit < 2W/10VA,I circuit <0.5VA per phase
- Power Factor- 0 lag-unity-0 lead
- Voltage & Frequency range- 3x240v/ 415v (-40% to +20%) at 50 Hz (5%)
- Short over current -30 Imax
- Storage and transport temperature range: -400C +800C
- Humidity Relative Humidity: Up to 95% non condensing
- Material -Engineering plastic (Polycarbonate
- Relay Type -Three Phase integrated relay for Load control
